Ums/D High Compression Ratio Pocket Spring Coiling Coiler Machine for Sale
Basic Info
Model NO. | LR-PS-UMS |
Wire Diameter | φ1.6-2.1mm |
Spring Type | Barrel, Cylindrical |
Waist Diameter Range | φ55-70mm |
Pocket Spring Height | 120-250mm |
Transport Package | Plywood Box or Pallet |
Specification | 10000x1650x2330mm |
Trademark | LianRou |
Origin | China |
Product Description
UMS/D High compression ratio pocket spring coiling coiler machine for sale
Stronger elasticity, lighter products and less consumables
1.Patented ultra-high spring pre-compression technology
2.Same wire diameter, stronger spring support
to reduce the cost of materials and transportation
3.Unique high compression ratio with high elasticity
achieve the same hardness product at a lower cost
Machine Specification
LR-PS-S(D)220 | Pocket spring machine | |
Model | LR-PS-S220 | LR-PS-D220 |
Production Capacity | 220 springs/min. | |
Coiling Head | Single wire servo coiling head/Double wire servo coiling head | |
Working Principle | Servo control | |
Spring Shape | Standard versions: barrel and cylindrical | |
Air consumption | Approx. 0.3m³/min. | |
Air Pressure | 0.6-0.7Mpa | |
Power Consumption in total | Approx.40KW | Approx. 43KW |
Voltage | 3AC 380V | |
Frequency | 50/60Hz | |
Input Current | 60A | 65A |
Working Temperature | +5ºC - +35ºC | |
Weight | Approx.6000Kg | Approx.7000Kg |
Consumption Material Date | |||
Non-woven fabric | Steel wire | ||
Fabric density | 65-90g/m2 | Wirediameter | 1.3-2.3mm |
Fabric width | 260~680mm | Inner dia.of wire roll | Min.320mm |
Inner dia.of fabric roll | 75mm | Outer dia.of wire roll | Max.1000mm |
Outer dia.of fabric roll | Max.1000mm | Acceptable weight of wire roll | Max.1000Kg |
Working Range(mm) | |||
Wire Diameter | Spring Waist Diameter | Pocket Spring Height | |
Option1 | φ1.6-2.3mm | Φ48-75mm | 80-250mm |
Option2 | φ1.3-1.9mm | Φ38-65mm | 60-220mm |
Product 3D Drawing
Patented U-loop spring conveyor provides long cooling time for the springsEquipped with a high-speed spring coiler for high production efficiency.Equipped with a high-speed spring coiler for high production efficiency.Patented high compression ratio push spring technology,with a compression ratio of up to 66%Spring production speed up to 160 pcs/min.Efficient welding, stable spring output, and good product quality.The spring has good resilience performance.With Enough time of cooling ,springs will result in that the spring reflects good bounce, making the mattress not easy to sagging!Consumables savingsIn the case of ensuring the same support, the use of fine steel wire will weigh less than coarse steel wire. For example, in the experiment, the wire diameter of 1.7mm compared with 1.9mm, according to various spring styles, it is conservatively estimated that each spring can save about 3g or more, and a single mattress core, depending on the size specifications, will save 3-5kg. According to the current price estimates of steel wire, it is expected that each mattress core can save 20-30 RMB. If we calculate the daily output of 500 mattresses, we can save about 10000 RMB for the manufacturer in a single day!Transportation savingThe same volume of mattresses, high compression ratio equipment to produce mattresses with lighter weight, transport costs are reduced accordingly. Therefore, it is more convenient to promote the use of electric business Company Introduction As the very first Chinese manufacturer of Pocket Spring Machines, Guangzhou Lianrou Machinery and Equipment (hereinafterrefer to as Lianrou) started the production of upholstered furniture equipments in China. Out of his own dozens of years experience onmachinery researching and manufacturing , founder of Lianrou developed the first Pocket Spring Machine in China. And this machinewon recognition and praises in Interzum Guangzhou Exhibition, from mattress enterprises and manufacturers of domestic and overseas.For many years after that, Lianrou has always kept in mind a belief of Technological Innovation, Quality First and Top Class Service.And he has continually researched and developed a series of upholstered furniture manufacturing equipments, Pocket Spring Machine,Pocket Spring Assembly Machine, Automatic Mattress Packing Machine, Mattress Roll-packing Machine, Foam-roll CompressingMachine,etc. In recent years, Lianrou has kept bringing in CNC Centers of famous international brands. Meanwhile, Lianrou has recruited plenty oftechnical talents with abundant experience and new concepts in machinery manufacturing,including software experts ,engineers withmaster degree and some doctor degree, and mechanism specialists who have gained national recognition.
